How To Prime A Well Pump: A Step-by-Step Plumbing Guide

Priming a well pump requires manually filling the pump housing and suction lines with water to purge trapped air and re-establish a continuous hydraulic vacuum. This process prevents motor damage from dry running and restores water pressure following power outages, plumbing repairs, or long periods of disuse. When executed systematically, priming takes 30 to 45 minutes using standard plumbing tools and clean potable water.

Pre-Priming Equipment Checklist and Operational Requirements

Above-ground centrifugal well pumps (shallow and deep-well jet pumps) rely on an air-tight seal and a continuous water column to pull groundwater into the pressure system. Unlike submersible pumps submerged directly in an aquifer, jet pumps cannot move air efficiently; attempting to run a dry pump causes immediate overheating, mechanical seal destruction, and impeller warp.

Before starting the priming process, ensure you have isolated the electrical system and prepared the necessary equipment to safely work on pressurized water lines.

Essential Gear, Tools, and Materials

• Safety Gear: Heavy-duty rubber gloves, safety glasses, and a non-contact voltage detector.
• Hand Tools: 10-inch and 12-inch adjustable pipe wrenches, flat-head and Phillips screwdrivers, slip-joint pliers, and a channel lock set.
• Consumables: High-density PTFE (Teflon) pipe thread tape, pipe thread sealant paste (pipe dope), and clean, potable water (typically 3 to 5 gallons).
• Filling Accessories: Clean plastic funnel, 5-gallon bucket, and a garden hose connected to an auxiliary water source (if available).

Mandatory Prerequisite Standards

• Electrical Isolation: The circuit breaker controlling the 115V or 230V well pump motor must be shut off and locked out before removing any access plugs.
• Pressure Relief: Residual pressure inside the pressure tank and distribution plumbing must be bled down to 0 PSI via the lowest drain valve or indoor faucet.
• Water Safety: Only use certified potable water to prime the pump to avoid introducing bacterial contamination into your residential water supply.

Operational Benchmarks

• Estimated Duration: 30 to 60 minutes for a standard shallow-well single-pipe system; 45 to 90 minutes for a deep-well double-pipe system.
• Estimated DIY Cost: $0 to $25 (covers thread tape, sealant, and fresh potable priming water).

Step-by-Step Execution of the Jet Pump Priming Workflow

Follow these sequential technical steps to manually prime your jet pump, purge trapped air pockets, and restore steady system water pressure.

Step 1: Disconnect Power and Bleed System Pressure

Locate your electrical service panel and switch the dedicated well pump circuit breaker to the "OFF" position. Verify that power is completely cut off by holding a non-contact voltage tester near the pump's pressure switch electrical terminals. Next, open the outdoor hose bibb closest to the pressure tank or an indoor sink faucet at the lowest elevation to completely drain residual line pressure. Observe the pressure gauge on the pump manifold to confirm it reads 0 PSI.

Warning: Never attempt to loosen or remove priming plugs while the system is under pressure or connected to live electricity. Pressurized water can blow out hardware, causing injury or eye hazards.

Step 2: Locate and Remove the Priming Plug

Examine the top of the cast iron or stainless steel pump housing (volute) to locate the designated priming port. This is usually a 1/2-inch or 3/4-inch square or hex-head threaded NPT plug sitting directly above the impeller chamber. On certain setups, an additional priming port may be positioned on the discharge tee adjacent to the pressure switch.

1. Clean debris, dust, or rust from around the plug threads using a wire brush to prevent contaminants from dropping into the impeller casing.
2. Use an adjustable pipe wrench to turn the plug counterclockwise.
3. Inspect the removed plug threads and the rubber O-ring or gasket (if equipped) for cracking, dry rot, or stripping. Replace damaged seals immediately.

Step 3: Inspect and Test Check Valve Functionality

A well pump cannot maintain a prime if the foot valve (at the bottom of the well pipe) or the inline check valve (near the pump inlet) is stuck open or leaking.

To test system integrity, insert a funnel into the open priming port and slowly pour 1 gallon of potable water into the chamber. Observe the water level inside the port throat:

• If the water remains steady near the top of the port, your check valve is holding correctly.
• If the water rapidly drops down the pipe, your foot valve or inline check valve is leaking or stuck open, letting water drain back into the well. Faulty foot valves must be cleaned or replaced before a prime can be established.

Step 4: Fill the Pump Volute and Suction Line

Insert a clean, narrow-neck funnel into the top priming port. Slowly pour clean, potable water into the opening to allow displaced air bubbles to escape from the suction line without sloshing over.

1. Continue pouring until water reaches the very top lip of the priming port opening.
2. Gently tap the sides of the metal pump casing and accessible suction piping with a rubber mallet to dislodge trapped air pockets along internal bends.
3. Pause for 2 to 3 minutes to allow air to burp out of the line. Top off the port with additional water as the level drops.
4. Repeat this process until the water level remains stable at the top of the port for at least 3 minutes.

Pro-Tip: If your setup includes a two-pipe deep-well jet pump, you must fill both the suction pipe and the smaller drive pipe completely. This requires patience, as air takes longer to escape through the restricted jet nozzle located down-hole.

Step 5: Wrap Threads and Reinstall the Priming Plug

Thoroughly clean the male threads of the priming plug using a clean cloth. Wrap the threads clockwise (in the direction the plug turns during tightening) with 3 to 5 full wraps of high-density PTFE tape. Apply a thin, uniform layer of non-hardening pipe thread sealant paste over the PTFE tape for an optimal seal.

Thread the plug into the port by hand to avoid cross-threading. Once hand-tight, use a pipe wrench to snug the plug down firmly. Do not over-torque, as cast iron and aluminum pump housings can crack under extreme mechanical stress.

Step 6: Restore Power and Monitor Pressure Cycle

Plug the well pump back in or switch the main circuit breaker to the "ON" position. The pump motor should engage immediately. Watch the system pressure gauge carefully during the operational cycle.

1. Pressure Build-Up: Within 1 to 3 minutes, the pressure gauge needle should rise smoothly from 0 PSI toward your system's cut-off threshold (typically 40 PSI or 60 PSI).
2. Listening for Cavitation: The motor should run with a steady, deep hum. A loud crackling sound (resembling rocks churning in a blender) indicates air cavitation inside the impeller.
3. Automatic Shut-Off: Once the system reaches its set cut-off pressure, the pressure switch should open and shut off the motor automatically.

Warning: If the pump runs continuously for more than 4 to 5 minutes without building pressure above 10-15 PSI, turn off the breaker immediately. Running the pump dry or unprimed for extended periods will melt the plastic diffusers and destroy the mechanical shaft seal.

Step 7: Purge Air from Household Plumbing Lines

Once the pump reaches cut-off pressure and shuts down, walk through the house and open every water fixture one by one—starting with the sink closest to the pressure tank.

Expect initial splattering, aggressive air bursts, and discolored water as trapped air and minor sediment purge from the plumbing lines. Allow each faucet to run until the stream flows clear, quiet, and steady, then turn it off. Check the pressure tank gauge to ensure the pump turns on at cut-in pressure (typically 20 or 40 PSI) and shuts off correctly at cut-off pressure.

Well Pump System Specifications and Operational Thresholds

Understanding your specific pump architecture and operational limits helps ensure accurate diagnostic and maintenance steps during the priming process.

Diagnosing and Resolving Well Pump Priming Failures

If your pump fails to hold a prime or cannot build system pressure after following the basic procedure, use these diagnostic pathways to locate and repair the issue.

Issue 1: Pump Motor Runs Continuously But Water Pressure Remains at Zero

• Root Cause: Severe suction-line vacuum leak or large trapped air pocket inside the pump volute preventing the impeller from engaging the water column.
• Actionable Fix: Turn off power immediately. Unscrew the priming plug and recheck water level. If empty, re-fill the volute completely. Inspect all threaded joints on the suction pipe for loose clamps or unsealed fittings. Apply thread sealant to all NPT adapters and repeat the priming sequence.

Issue 2: System Holds Prime Temporarily But Loses Pressure Overnight

• Root Cause: A failing foot valve at the base of the drop pipe, a leaking check valve, or a pinhole corrosion leak in the well drop pipe letting water drain back into the aquifer.
• Actionable Fix: Install an inline check valve directly on the suction line before the pump inlet as a temporary fix. For a permanent solution, pull the drop pipe from the well casing and replace the foot valve and damaged pipe segments.

Issue 3: Pump Spews Water and Air Intermittently from Household Faucets

• Root Cause: Micro-fractures in the PVC/PE suction pipe, a falling water table exposing the foot valve screen to air, or a waterlogged pressure tank bladder.
• Actionable Fix: Measure the standing water level in your well to confirm the pump intake is fully submerged. Check the pressure tank air pre-charge through the Schrader valve using a tire gauge (it should read 2 PSI below the pump cut-in pressure). Replace the tank bladder if water bleeds out of the air valve.

Issue 4: Water Leaks from Behind the Pump Motor Casing During Priming

• Root Cause: Blown mechanical shaft seal or cracked pump volute caused by winter freezing or running dry.
• Actionable Fix: Disassemble the pump wet end and inspect the ceramic/carbon mechanical seal located behind the impeller. Replace worn seals or purchase a replacement wet-end assembly if the cast housing shows hairline freeze cracks.

Frequently Asked Questions

How do I know if my well pump has lost its prime?

You will know your well pump has lost its prime if the electric motor runs continuously without generating water flow at your indoor faucets, or if your system pressure gauge drops to 0 PSI and fails to rise. Additionally, you may hear a higher-pitched, dry whirring sound from the pump casing, indicating the impeller is spinning in air instead of water.

Can a jet well pump re-prime itself automatically?

Standard shallow and deep-well jet pumps cannot re-prime themselves automatically because air compresses under pressure while water does not, preventing centrifugal impellers from pulling a vacuum in air. Only submerged pumps or specialized self-priming utility pumps can clear air from their chambers without manual water injection.

Is it safe to use water from a garden hose to prime my well pump?

It is safe to use water from a garden hose only if the source hose is connected to a clean, tested potable water supply. Never use untreated water from ponds, streams, or rain barrels to prime a pump, as this introduces dangerous bacteria, organic silt, and abrasive grit into your home plumbing and pressure tank.

How many times can I attempt to prime my well pump before causing damage?

You can attempt the priming process 3 to 4 times consecutively, provided you do not allow the pump motor to run dry for more than 2 minutes per attempt. If the pump fails to catch a prime after four full attempts, stop and troubleshoot for suction line air leaks, dry well conditions, or broken foot valves to avoid overheating the motor windings.

Why does my well pump keep losing its prime every time it shuts off?

Repeated loss of prime upon motor shut-off indicates that water is draining backward out of the pump housing and down into the well. This is almost always caused by a failing foot valve seal at the bottom of the well, a damaged inline check valve, or an unsealed NPT pipe fitting on the suction line that admits air into the system when vacuum pressure drops.

Restore Your Water System's Reliability

If your well pump consistently struggles to hold a prime despite replacing check valves and sealing suction fittings, your water system may require advanced diagnostic testing or equipment replacement. Contact a licensed local groundwater contractor or certified plumbing specialist to evaluate your well depth, drawdown rate, and pump sizing today.
